Technical Data
General
| Product number | 112849 |
|---|---|
| EAN | 4003718042962 |
| max flow rate l / h | 4000 LPH |
| Max. Delivery Head in m | 45 M |
| Max. Suction Height in m | 8 M |
| Max. Pressure in bar | 3.8 BAR |
| Pump Drive | 1-stage |
| Protection Against Dry Running | No |
| Net Weight in kg | 17.9 KG |
| Switch-on Pressure bar | 2 BAR |
| Switch-off Pressure bar | 3.5 BAR |
| Vol of Pressure Vessel (L) | 17 L |
| Gross Weight in kg | 21 KG |
| Height in cm | 64.7 CM |
| Width in cm | 28.4 CM |
| Length in cm | 47.8 CM |
| Filter | Yes |
| Sound Power Guar LwA[dB (A)] | 78 |
| Cable Length in m | 1 M |
| Product Range | Comfort |
| Brand | AL-KO |
Engine
| Motor power in watts | 1000 W |
|---|
Download Manuals
| Product Manual |
Download (3.72MB) |
|---|---|
| EC Declaration of Conformity |
Download (1.5MB) |
FAQ
Domestic waterpumps has the advantage of pumping automatically. Often electronicly controlled and with a pressure tank. Pressure pumps delieveres water pressure but with an on/off switch system. Forexample to to run a garden sprinkler system.
Using the ECO mode causes the domestic waterworks to switch off at a lower pressure. This means that the domestic waterworks runs for a shorter time and thus consumes less electricity.
No, garden pumps and domestic waterworks must always be set up horizontally
Dirty water is referred to: sediment-rich flowing waters, brackish water (mixture of salt and fresh water), flood water, pond water (if inlet without filtering)
Dirty water is therefore water with suspended and sedimentated matter as an admixture in the medium.
Having the pumps certified for drinking water would require fulfill many legal requirements and this would make the device too expensive. Most of the pumps and domestic water supply systems in this category are not intended for drinking water.
The AL-KO pumps are built exclusively for use with water. Salt water, alkalis, fruit juices, lime lye, cement broth or other media may not be extracted.
